VOLVO/IVECO Brake Lining Kit 2712495

Front Axle, Rear Axle Drum Diameter : 381 mm Width : 177.8 mm Thickness : 18.6/12.6 mm Outer Length : 207 mm Inner Length : 188 mm Radius : 184 mm Number of holes : 12

IVECO Brake Lining Kit 424 999 76

Rear Axle Drum Diameter : 325 mm Width : 80 mm Thickness : 7 mm Outer Length : 268/311 mm Inner Length : 256/298 mm Radius : 155 mm Number of holes : 12/14

Brake Lining Kit 190 2483

Front Axle, Rear Axle Drum Diameter : 410 mm Width : 200 mm Thickness : 18/11.2 mm Outer Length : 220 mm Inner Length : 207.2 mm Radius : 200 mm Number of holes : 14/12

Brake Lining Kit 0309220150

Rear Axle Drum Diameter : 400 mm Width : 80 mm Thickness : 8 mm Inner Length : 389 mm Number of holes : 10

Brake Lining Kit 681 290

Rear Axle Drum Diameter : 419 mm Width : 203 mm Thickness 1 : 18.5/9.4 mm Thickness 2 : 18.5/15.8 mm Outer Length : 229/191 mm Inner Length : 212.9/175.6 mm Radius : 203 mm Number of holes : 20/16

MERCEDES BENZ/IVECO Brake Lining Kit 611 423 22 10

Rear Axle Drum Diameter : 270 mm Width : 79 mm Thickness : 8 mm Outer Length : 224/259 mm Inner Length : 211/244 mm Radius : 127 mm Number of holes : 12/14

MERCEDES BENZ Brake Lining Kit 000 421 01 31

Rear Axle Drum Diameter : 410 mm Width : 220 mm Thickness 1 : 18.55 mm Thickness 2 : 18.5/7.4 mm Thickness 3 : 18.6/16.8 mm Outer Length : 210 mm Inner Length : 196 mm Radius : 201 mm Number of holes : 12

Brake Lining Kit 0309228310

Front Axle, Rear Axle Drum Diameter : 420 mm Width : 220 mm Thickness : 17.7/11.7 mm Outer Length : 220 mm Inner Length : 203 mm Radius : 205 mm Number of holes : 10

DAF Brake Lining Kit 683016

Rear Axle Drum Diameter : 419 mm Width : 178 mm Thickness 1 : 18.5/9.5 mm Thickness 2 : 18.5/13.5 mm Outer Length : 227/236 mm Inner Length : 208/216 mm Radius : 203 mm Number of holes : 14

MERCEDES BENZ Brake Lining Kit 309 421 07 10

Front Axle, Rear Axle Drum Diameter : 300 mm Width : 70 mm Thickness : 9 mm Outer Length : 307/261 mm Inner Length : 288/245 mm Radius : 140 mm Number of holes : 12/14

Brake Lining Kit 552120

Front Axle, Rear Axle Drum Diameter : 413 mm Width : 178 mm Thickness : 19.1 mm Outer Length : 213 mm Inner Length : 193 mm Radius : 188 mm Number of holes : 12

Brake Lining Kit 0309211080

Front Axle, Rear Axle Drum Diameter : 300 mm Width : 60 mm Thickness : 5 mm Outer Length : 300 mm Inner Length : 290 mm Radius : 145 mm Number of holes :16

VOLVO Brake Lining Kit 272890

Front Axle, Rear Axle Drum Diameter : 394 mm Width : 177.8 mm Thickness 1 : 19.1/11.7 mm Thickness 2 : 19.1/14.8 mm Outer Length : 210/160 mm Inner Length : 191/146 mm Radius : 192 mm Number of holes : 12/9

Brake Lining Kit 0309218120

Front Axle, Rear Axle Drum Diameter : 350 mm Width : 60 mm Thickness : 6 mm Inner Length : 339 mm Number of holes : 10

VOLKSWAGEN Brake Lining Kit 281 698 135

Rear Axle Drum Diameter : 252 mm Width : 55 mm Thickness : 6 mm Inner Length : 201/260 mm Number of holes : 8/10
