Heavy Duty Trailer Torsion Axles Austraila
| American Drum Series Axle | ||||||||||
| Item No. | Capacity (T) | Track (mm) | Axle Beam (mm) | Center Distance Of Chamber (mm) | Brake Spec.(mm) | Wheel Fixing (mm) | Wheel Rim | Total Length (mm) | Weight (Kg) | Bearing |
| L2 | L3 | D1×D2 | L1 | Inner/Outer | ||||||
| LHAD08-A01 | 8 | 1840 | 127/ 150 | 455 | S 420×150 | 8×M20×Φ285×Φ221 | 7.5V-20 | 2185 | 320 | 33215/33213 |
| LHAD11-A01 | 11 | 1960 | 127 | 670 | S 310×190 | 10×M22×Φ285.75×Φ221 | 6.5-16 | 2250 | 347 | 218248/218248 |
| LHAD13-A01 | 13 | 1840 | 127/ 150 | 388 | S 420×180 | 10×M22×Φ335×Φ281 | 7.5V-20 | 2185 | 362 | HM518445/10 |
| LHAD13-A02 | 13 | 1840 | 127/ 150 | 388 | S 420×180 | 8×M20×Φ285×Φ221 | 7.5V-20 | 2185 | 365 | HM518445/10 |
| LHAD14-A01 | 14 | 1840 | 127/ 150 | 348 | S 420×180 | 10×M22×Φ285×Φ281 | 8.0V-20 | 2192 | 408 | |
| LHAD15-A01 | 15 | 1850 | 127/ 150 | 396 | S 420×180 | 10×M22×Φ285×Φ281 | 8.0V-20 | 2185 | 382 | HM518445/10 |
| LHAD16-A01 | 16 | 1850 | 127/ 150 | 354 | S 420×220 | 10×M22×Φ285×Φ281 | 8.5V-20 | 2205 | 425 | HM220149/10 |
| LHAD20-A01 | 20 | 1850 | 150 | 354 | S 420×220 | 10×M24×Φ285×Φ281 | 8.5V-20 | 2270 | 460 | 32222 HM518445/10 |
| The track can be met according to customers'requet | ||||||||||
| German Drum Series Axle | ||||||||||
| Item No. | Capacity (T) | Track (mm) | Axle Beam (mm) | Center Distance Of Chamber (mm) | Brake Spec.(mm) | Wheel Fixing (mm) | Wheel Rim | Total Length (mm) | Weight (Kg) | Bearing |
| L2 | L3 | D1×D2 | L1 | Inner/Outer | ||||||
| LHAD10-E01 | 10 | 1840 | 150 | 421 | S 420×180 | 10×M22×Φ335×Φ281 | 7.5V-20 | 2160 | 360 | 33118/33213 |
| LHAD12-E01 | 12 | 1840 | 150 | 421 | S 420×180 | 10×M22×Φ287.74×Φ220 | 7.5V-20 | 2172 | 360 | 33118/33213 |
| LHAD14-E01 | 14 | 1840 | 150 | 429 | S 420×200 | 10×M22×Φ335×Φ281 | 7.5V-20 | 2245 | 420 | 32219/33215 |
| LHAD16-E01 | 16 | 1840 | 150 | 243 | S 420×200 | 10×M22×Φ335×Φ281 | 8.0V-20 | 2245 | 460 | 32222/32314 |
| LHAD18-E01 | 18 | 1840 | 150 | 263 | S 420×220 | 10×M22×Φ287.75×Φ281 | 8.5V-20 | 2245 | 540 | 32222/32314 |
| The track can be met according to customers'requet | ||||||||||





Xiamen Lahoo Auto Parts Co., Ltd. is a leading supplier in auto parts that organized by several factories and joint-ventured manufacturers which successfully certified with TS16949 and ISO9001/2000 quality control system. We can supply full range spare parts for full trailers, semi-trailers, heavy duty trucks, light duty trucks, Our main spare parts include leaf spring, wheel rim, axle, Mechanical suspension, air suspension, boogie, turntable, fifth wheel, king pin, landing gear, air chamber, twist lock, Towing Hitches, Bearing and so on.
