AA4C Clutch pressure Plate & Flywheel Grinder FG500

  • Factory price: There is no set price, you can ask the supplier to get a product quote
    Initial batch size:
     123412 ¥310
  • Delivery merchant:Shanghai AA4C Auto Maintenance Equipment Co., Ltd.
  • Condition: New Type: Horizontal
    CNC or Not: CNC Automatic Grade: Automatic
    Place of Origin: China (Mainland) Brand Name: AA4C
    Model Number: AA-FG500 Voltage: 380V
    Dimension(L*W*H): 1500*990*1650 mm Certification: CE
    Machine Type: Flywheel grinder Name: Flywheel grinder
    Color: Customized Option Grinding wheel diameter: 150 mm
    Max. machine diameter of workpiece: 500 mm Warranty: One Year
    Function: Flywheel grinding machine Spindle speed: 2840 r / min
    Speed of worktable: 36 r / min Motor power of cooling pump: 0.12kw
    Max. Swing Diameter: 500mm After-sales Service Provided: Engineers available t
    Power(W): 3KW Weight: 800kg
  • Purchase type:
  • Offers:

    This product is free of shipping

    Full(999$L元)$can be reduced15 yuanShipping costs, while you run out.

    Full999 yuanGet beautiful for freeFreebies,While supplies last。

  • Net content:5000g
  • Specifications:
  • Delivery to:

    Please select the receiving city

    Please select
    Please select
    Please select
  • Purchase quantity:
    Inventory0pieces
Product Description



Product Application

Features:



Use and performance of the vehicle repair industry is grinding to repair the vehicle flywheel special machine tools, has a simple structure and reliable performance characteristics such as grinding may be less than the diameter of the fly wheel 500mm ,The rigid machine tool performance, the work of high precision, fast speed, processing efficient, simple and convenient maintenance is and ideal tool for special flywheel grinding.

The type of grinding machine Tool grinder.



Model
FG500
Table Diameter
450mm
The Max diameter of repairing Flywheel
500 mm
The Max Distance from spindle to table
200mm
Rotational Speed of Grinding wheel
2800r/min
The rotational speed of table
17/34r/min
The motor of grinding wheel
3 kw/400V/50HZ
The motor of table
1400/700r/min 0.4/0.22KW/400V/50HZ
Cooling pump
0.12KW
Overall dimensions
1200X800X1750(mm)
