Emergency shut valve is installed on the bottom of the tanker,thetop parts is tightly sealed inside the tanker.Externalshear groove design limits product spillage when the tanker is crashed down,itwill automatically cut off itself via this groove under the situation there's no affectation on the sealing. This will efficiently protect the over rooledtanker from leakage to ensure the safety when transportation.Thisproduct is suitable for water,diesel,gasolineand kerosene and other light fuel,etc.
Benefit and features
��Special syrfacetreatmentThe whole valve body is passed a special surface process to improve the anti-corrosion.
��Hydrodynamic bodyDesign and high lift poppet minimizes pressure drop to give maximum flow rate.
��External shear grooveMeets the standard requirements to limit product spillage in the event of an accident.
��Two Ways-OperationIf need,canbe installed a outernalcylinder to do the pneumatic control.
��Easy‐InstallmentThe size of the valve is more smart,issuitable for the smaller space's demand.
Technical Data
Nominal diameter 3"4"
Working pressure 0.6MPa
Open method Mechanical
Temperature range ‐20~+70℃
Material Aluminum alloy
Delivery: 7 days upon received deposit payment
