HF2060 Steam and Micro Hot Pressure Water Steam Car Washer
Basic Information:
1. Feature(Addtional micro hot pressure water function for thick mud)
220V 1ph electricity power, single steam gunjets. It has steam humidity adjustment function for dry steam (clean for car interior and engine), wet steam (clean for car exterior and tire, etc.) as well as 8bar micro hot pressure water assistant in washing thick mud.
2. Application Area
Car wash shop, underground car wash business, parking lot (in supermarket, living department, industry zoom, park, etc.)
3. Function
Remove dust, oil, insect body, ice-cream, coke stains, etc. Full cleaning, disinfection and bad smell killing on car interior, exterior and engine.
4. Technical Parameter
Power resource | 220-240V AC 1ph, 50-60Hz |
Power | 6KW (Standby no loss) |
Steam Pressure | 0.8 MPa (8bar or 116psi) |
Steam Gunjet No. | 1 |
Max Steam Temperature | 170℃ |
Effective Operating Temperature | 60℃-120℃ |
Water Consumption Rate | 13kg/h |
Humidity Adjustment | Available for dry and wet steam |
Continuous Work Time | Non-stop, All day long |
Size | 920(mm)x440(mm)x780(mm) |
Net Weight | 70 kgs |
Tank Capacity | 18 Liters (Can automatically supply by external water connection) |
Material | Stainless steel, Hi-Q sodium silicate for heat preservation & insulating |
Hose Length | 10 meters |
5. Protection system
1) Current leakage automatically shutdown protection.
2) Overheat automatically shutdown protection.
3) Water shortage alarming and automatically shutdown protection.
4) Overpressure protection automatically shutdown protection, and the safety valve will also take effect to release pressure.
6.Advantage
1)Water& Energy Saving——1.5-2L, 0.8KW.H wash a car
2)Multi-function: Car inside, outside and engine washing——One Stop Wash
3)Steam Humidity Adjustment: stepless regulation
4)Environment Friendly: Free from detergent, but wonderful cleaning effect
5)Disinfection and Smell Removing,360 degree no dead corner
6)Mobile and Automacted Controlled: Texas imported chip, LCD display for working condition and defaults.
7)Various Models
Saturated Steam & High Pressure
Micro Hot Water & Self Service & Customized models
8)Multiple Safety Protection Measure: Digital detecting(pressure, temperature, water level) and alarm protection system; Safety valve; Shutdown protections of over-pressure, water shortage, electricity leaking and accident.
9)Durable: Stainless steel body, Hi-Q sodium silicate for heat preservation & insulating.
10)Imported Electricity Components and Important Parts.
11)Short Steam Generating Time, Steam Standby All the time.
12)Modularized Parts for Easy Maintenance.
13) Working All Day Long, Stable Pressure.
14)Guarantee: One year.
15) Inner Self Clean: Unique cleaning design of tank bottom, cleaning up the scale easily!
16) Certification: CE (European Certificate) & National QS Test
7. Advice on model choices
1) If you only have 220-240V 1ph electricity system, HF1060, HF2060 are suggested to you;
2) If you can have 380-420V 3ph electricity system, HF1090 and HF2090 are suggested, as they are of higher cost performance.
3) If the cars are of thick mud, HF2060 or HF2090 are suggested with the additional function of micro hot pressure water.
4) If your electricity system are not stable, or you want to offer door to door car wash services, LPG powered model HA1190 is suggested to you.
