10 year Super Bright LED Halo Rings and LED Angel Eye for bmw e60 e90 e92 angel eye led
B-M-W (with stock equipped Angel Eyes / Xenon Headlights Only):
08-12 B-M-W 1-series E82/E87 (128i, 135i)
09-11 B-M-W 3-series E90 sedan Face lifted (328i, 328xi, 335d, 335i)
09-11 B-M-W 3-series E91 touring Face lifted (328i, 328xi)
07-12 B-M-W 3-series E92 coupe (328i, 328xi, 335i)
08-12 B-M-W 3-series E92 M307-12 B-M-W 3-series E93 convertible (328i, 335i)
08-10 B-M-W 5-series E60 sedan Face lifted (528i, 528xi, 535i, 535xi, 550i)
08-10 B-M-W 5-series E61 touring Face lifted (535xi)
08-10 B-M-W 6-series E63/E64 Face lifted (650i)
07-12 B-M-W X-series E70 X508-12 B-M-W X-series E71 X6
09-12 B-M-W Z-series E89 Z4
B-M-W Original Part Numbers:63217760782
1.Main parts are made up of 180W/m.k high thermal conductivity aluminum alloy material, sufficient heat dissipation.
2.The stable temperature of the surface is controlled less than 85°C , which can improve the product stability and life.
3. Angel Eyes Used the brightest C-R-E-E XB-D R3,
the bright of single LED can reach to 268LM; The thermal resistance can reached to 9°C/W;
And the maximum junction temperature can reach to 150°C
4. Angel Eyes Used greater than 2W/MK thermal conductivity of the aluminum base, The thermal resistance is less than 0.8°C/W;
5. Angel Eyes Used the thermal conductivity of the thermal grease is greater than 4W/MK.
6. Angel Eyes LED Maximum power output is greater than 8W
7.No flickers, no errors, no warnings, no interference to FM radio;
8.Strictly control production process, and do 100% tests for per pc: operating current testing,, brightness testing,, color temperature testing, and aging testing;
Professional design, can be able to meet the special requires for special products,Able to professionally design personalized products for quests.
Absolute Maximum Ratings at Ta=25 °C
High quality Auto LED daytime running light ,led side marker,DRL angel eyes for b-m-w e60
Parameter | Symbol | Rating | Unit |
Angel Eyes Power Dissipation | P | 9 | W |
Angel Eyes Input Voltage Range | VIN | 9-30 | V |
Angel Eyes Input Current | IIN | 0.69A/DC13.5V | A |
Angel Eyes Output Voltage | VLED | 6.4 | V |
Angel Eyes Output Current | ILED | 1.25 | A |
Angel Eyes Power Efficiency | η | >90 | % |
Angel Eyes Power Reverse Polarity Protection |
| YES |
|
EMC Protection |
| YES |
|
Output Short Circuit Protection |
| YES |
|
Output Open Circuit Protection |
| YES |
|
Angel Eyes Luminous Flux | MAX | 788 | lm |
Angel Eyes Luminous Flux | MIN | 700 | lm |
Angel Eyes Correlated Colour Temperature |
| 7000K-8000K | K |
Angel Eyes Surface Temperature | MAX | 85 | °C |
Angel Eyes LED Temperature | MAX | 90 | °C |
Viewing | MAX | 115 | deg |
Angel Eyes Operating Temperature Range | Topr. | -40 to +95 | °C |
Angel Eyes Storage Temperature Range | Tstg. | -40 to +125 | °C |
Note: 1.IV is measured with an accuracy of ±5%
2.Luminous Flux ±5%
Typical Electrical/Optical Characteristic Curves(25°C Ambient Temperature Unless Otherwise Noted)
E4 &R87 High quality Auto LED daytime running light ,led side marker,DRL angel eyes for b-m-w e60
