high pressure wire spiral rubber hydraulic hose 4SP 4SH(Competitive price)

Factory price： There is no set price, you can ask the supplier to get a product quote

Initial batch size：
123412 ¥310 ~~¥Unset Price~~
Delivery merchant：Hebei Dayi Rubber Products Co., Ltd.

Place of Origin：	Hebei, China (Mainland)	Brand Name：	DAYI, DAYI FLEX
Model Number：	4SP 4SH, 4SP 4SH	place of origin：	Hebei,China(Mainland)
hydraulic hose length：	100m/50m	hydraulic hose color：	black,blue
hose size：	1/4-2 inch	working tempreture：	-40Degree to +100Degree
delivery time：	within 10days for a 20 container	Certification：	ISO9001:2008

Purchase type： Foundry production Manufacturer's own brand
Promotional price：Promotion¥0.0
Offers：

This product is free of shipping

Full(999$L元)$can be reduced15 yuanShipping costs, while you run out.

Full999 yuanGet beautiful for freeFreebies，While supplies last。
Net content：5000g
Specifications：

Delivery to：
Please select the receiving city
Please select

Please select

Please select
Purchase quantity：

Inventory0pieces 【Complimentary】

Product Description

EN856 4SH hydraulic hose

CONSTRUCTION:
This hose consists of an inner tube of oil synthetic rubber, 4 wires braid reinforcement, and an oil and weather resistant synthetic rubber cover.
APPLICATIONS:
Hose range suitable to carry hydraulic fluids such as glycol, mineral oils,fuels,lubrication,emulsion,hydrocarbons etc.
WORKING TEMPERATURE:
From-40°C up to +100°C

Nominal		Inside		Reinforcement		Outside	Working		Proof	Burst	Min.Bend	Weight
diameter		Diameter		Diameter		Diameter	Pressure		Pressure	Pressure	Radius	Kg/m
		mm		mm		mm	MPa		PSI	PSI	mm
mm	inch	min	max	min	max	max	max	PSI		min
19	3/4"	18.6	19.8	28.3	29.1	32.5	42	6090	12180	24360	280	1.7
25	1"	25	26.4	35.4	36.2	40	38	5510	11020	22040	340	2.5
31	1-1/4"	31.4	33	42.2	43	47.1	32.5	4713	9425	18850	460	3
38	1-1/2"	37.7	39.3	49	49.8	55	29	4205	8410	16820	560	3.6
51	2"	50.4	52	63.4	64.2	69.3	25	3625	7250	14500	700	5

hydraulic hose 4SP technical data

Nominal		Inside		Reinforcement		Outside	Working	Working	Proof	Burst	Min.Bend	Weight
diameter		Diameter		Diameter		Diameter	Pressure	Pressure	Pressure	Pressure	Radius	Kg/m
		mm		mm		mm	MPa	PSI		PSI	mm
mm	inch	min	max	min	max	max	max	max	PSI	min
10	3/8"	9.3	10.1	17.4	18.2	22	44.5	6453	12905	25810	180	0.78
12	1/2"	12.3	13.5	20.3	21.1	25	41.5	6018	12035	24070	230	0.93
16	5/8"	15.5	16.7	23.8	24.6	28.5	35	5075	10150	20300	250	1.17
19	3/4"	18.6	19.8	28.3	29.1	33	35	5075	10150	20300	300	1.48
25	1"	25	26.4	35.4	36.2	40	28	4060	8120	18560	340	2.02
31	1-1/4"	31.4	33	45.1	45.9	51	21	3045	6090	12180	460	3.05
38	1-1/2"	37.7	39.3	51.6	52.4	57.5	18.5	2683	5365	10730	560	3.52
51	2"	50.4	52	64.6	65.4	71.5	16.5	2393	4785	9570	660	5.2
