3.0" Turbo Pipe Hose Coupler T-bolt Clamp

  • Factory price： There is no set price, you can ask the supplier to get a product quote
    Initial batch size：
     123412 ¥310
  • Delivery merchant：Shanghai Engin Industry Co., Ltd.
    • Place of Origin： Shanghai, China (Mainland) Brand Name： LIK Racing
    Model Number： LIK-TCL-3.0 Band Material： stainless steel
    Size： 3.0" Stud material： Zinc coated Carbon Steel
    Nut： Self-lock nut Sample： available
    Warranty： 12 months under normal use
  • Purchase type：
  • Offers：

    This product is free of shipping

    Full(999$L元)$can be reduced15 yuanShipping costs, while you run out.

    Full999 yuanGet beautiful for freeFreebies，While supplies last。

  • Net content：5000g
  • Specifications：
  • Delivery to：

    Please select the receiving city

    Please select
    Please select
    Please select
  • Purchase quantity：
    Inventory0pieces





Type:  T- Clamp


Band material:  Stainless Steel


Stud material:Zinc coated Carbon Steel


Nut: Self-lock nut


Band Width:19mm


Clamping range: 3" (79mm to 87mm)





Notice:







The size listed is the size silicone hose this clamp will fit over.







The actual size is larger than the listed,so please make sure







to check the clamping range.















How to choose the T clamp:







1, Calculate your hose Outside diameter







2, Check our clamping range







3, Make sure your Hose OD are between our clamp range.











For example:







1, If you have a 2.5" (63.5mm) ID silicone hose, then calcuate your hose OD= 63.5+5x2=73.5mm







2, Check our clamping range







3, Choose our 2.5" T clamp which clamping range are 67mm to 75mm as what you need,







   because your Hose OD are between our 2.5" T clamp's clamping range 67mm to 75mm.











Details clamping range of our T clamps as below:







T clamp Size        Clampring range







1"                  31mm to 36mm







1.25"               37mm to 42mm







1.5"                43mm to 49mm







1.75"               47mm to 57mm







2"                  54mm to 62mm







2.25"               60mm to 68mm







2.5"                67mm to 75mm







2.75"               73mm to 81mm







3"                  79mm to 87mm







3.25"               86mm to 94mm







3.5"                92mm to 100mm







3.75"               98mm to 106mm







4"                  104mm to 112mm

















We are able to provide you with small amount free sample for the purpose of quality verification, we do believe that you will be satisfied with our products when you see our products,customer will be require to pay the freight for free sample post,however,the freight charges can be save in the first order.



If sample order total amount more then USD30,it will be on customer's account. Most samples will

be ready within 2days,and will be delivered to customers with in 3days,please allow 3-10 business

days for samples to arrive,thanks.













Most of the free sample order or small amount sample order will be shipped through our authorised express company,such as DHL,UPS,TNT,Fedex,EMS,we select the fast and reliable way for delivery.











a.We welcome customized products according to your picture,technical drawing or prototype.
b.We can add your company label or logo on the products.
c.Any questions you meet,anytime,can contact us freely
